Temperature range: - 60 ℃ - + 200 ℃

Conductor: tin plated copper wire, silver plated copper wire

Insulator: silicone rubber

Color: white, blue, red, black, brown, yellow, green

Specified voltage of wire: DC 5kv-60kv

Use characteristics: DC voltage, good flexibility, high-voltage tester, high-voltage neon lamp, etc.

Wire specification

型号 Model	导体截面积 Conductor section mm	绝缘层厚度 Insulating thickness mm
AGG-5KV	0.2~4	1.0
AGG-12KV	0.2~4	1.3
AGG-15KV	0.2~4	1.7
AGG-20KV	0.2~4	1.8
AGG-25KV	0.2~4	2.8
AGG-30KV	0.2~4	3.2
AGG-40KV	0.2~4	4.2
AGG-50KV	0.2~4	5.5
AGG-60KV	0.2~4	7.0
注：特需规格可以定制生产。
