Rated voltage: 600V
Voltage withstand test: 2000V
Temperature range: - 60 ~ + 200 ℃
Conductor: tinned copper wire stranded
Color: red, yellow, blue, white, black, yellow green, brown, green, etc.
Product performance: it has excellent high temperature and low temperature resistance, excellent electrical insulation performance, excellent chemical stability, and is very soft, aging resistant and long service life.
Product application: it is widely used in lighting fixtures, household appliances, electric appliances, instruments and meters, motor lead wires, electronics, lamps, gas appliances and other high-temperature environments.
Delivery length: short line sections not less than 10m are allowed, but the quantity shall not exceed 10% of the total delivery quantity.
Wire specification
| 导体 | 绝缘体 | 导体电阻（m/km） | 米/卷 | ||||
| 线号 | 标准截面（mm2） | 导体构造（mm） | 直径（mm） | 绝缘厚度（mm） | 完成外径（mm） | ||
| 24 | 0.22 | 1*0.50 | 0.50 | 0.60 | 1.80 | 89.39 | 610 |
| 22 | 0.33 | 1*0.60 | 0.60 | 0.60 | 1.90 | 54.30 | 610 |
| 20 | 0.52 | 1*0.80 | 0.80 | 0.60 | 2.10 | 33.90 | 305 |
| 18 | 0.81 | 1*1.00 | 1.00 | 0.60 | 2.30 | 21.40 | 305 |
| 16 | 1.31 | 1*1.20 | 1.20 | 0.65 | 2.60 | 13.50 | 305 |
| 24 | 0.22 | 7*0.20 | 0.61 | 0.60 | 1.91 | 93.25 | 610 |
| 22 | 0.33 | 7*0.25 | 0.76 | 0.60 | 2.06 | 55.00 | 610 |
| 20 | 0.52 | 7*0.31 | 0.95 | 0.60 | 2.25 | 34.60 | 305 |
| 18 | 0.81 | 7*0.39 | 1.19 | 0.60 | 2.49 | 21.80 | 305 |
| 16 | 1.31 | 7*0.50 | 1.53 | 0.65 | 2.93 | 13.70 | 305 |
| 14 | 2.08 | 37*0.26 | 1.83 | 0.70 | 3.33 | 8.62 | 200 |
| 12 | 3.31 | 45*0.32 | 2.48 | 0.80 | 4.18 | 5.43 | 100 |
| 10 | 5.3 | 35*0.45 | 3.08 | 0.90 | 4.98 | 3.41 | 100 |
