Rated voltage: 300V

Voltage withstand test: 2000V

Temperature range: - 60 ~ + 200 ℃

Conductor: tinned copper wire stranded wire

Insulation: silicone rubber

Color: red, yellow, blue, white, black, yellow green, brown, green, etc.

Delivery length: short line sections not less than 10m are allowed, but the quantity shall not exceed 10% of the total delivery quantity.

Product performance: it has excellent high-temperature and low-temperature resistance, excellent electrical insulation performance, excellent chemical stability, especially soft, aging resistance and long service life.

Product application: it is widely used in lighting fixtures, household appliances, electric appliances, instruments and meters, motor lead wires, electronics, lamps, gas appliances and other high-temperature environments.

Wire specification

导体				绝缘体		导体电阻（m/km）	米/卷
线号	标准截面（mm2）	导体构造（mm）	直径（mm）	绝缘厚度（mm）	完成外径（mm）
24	0.22	7*0.20	0.61	0.78	2.17	93.25	305
22	0.33	7*0.26	0.80	0.78	2.36	55.00	305
20	0.52	7*0.30	0.92	0.78	2.48	34.60	305
18	0.81	7*0.39	1.19	0.78	2.75	21.80	305
16	1.31	7*0.50	1.53	0.78	3.09	13.70	305
14	2.08	37*0.26	1.83	0.90	3.63	8.62	305
12	3.31	45*0.32	2.48	1.00	4.48	5.43	200
10	5.3	35*0.45	3.08	1.10	5.28	5.43	200
