Product executive standard: ul758-2000

Rated voltage: 600V

Temperature range: - 65 ~ + 200 ℃

Conductor: solid core or stranded tinned copper wire

Insulation: FEP fluoroplastic

Color: red, yellow, blue, white, black, green, brown, etc

Delivery length: short line sections not less than 10m are allowed, but the quantity shall not exceed 10% of the total delivery quantity;

Product performance: with excellent corrosion resistance, it can resist oil, strong acid, strong alkali, strong oxidant, etc; It has excellent electrical insulation performance, high voltage resistance, low high frequency loss, no moisture absorption, and large insulation resistance; It has excellent fire resistance, aging resistance and long service life.

Product application: internal wiring of microwave ovens, electronic products, lamps, electric heaters, ovens, power plants, various vehicles, etc. in the electronic industry, household appliances industry.

Wire specificat

线规 （AWG）	导体结构 根数/线径（mm）	绝缘厚度 （mm）	电线外径 （mm）	20℃时导体直流电阻（Ω/km）	包装长度 （m）
10	37*0.43	0.51	4.03	3.546	305
12	19*0.49	0.51	3.47	5.64	305
14	19*0.37	0.51	2.87	8.96	305
16	19*0.30	0.51	2.52	14.6	305
17	19*0.26	0.51	2.32	18.3	305
18	19*0.23	0.51	2.17	23.2	305
20	19*0.20	0.51	1.97	36.7	305
	1*0.80	0.51	1.82	35.2	305
22	19*0.16	0.51	1.82	59.4	610
	1*0.65	0.51	1.67	56.4	610
24	7*0.20	0.51	1.62	94.2	610
	1*0.50	0.51	1.52	89.3	610
26	7*0.16	0.51	1.50	150	610
	1*0.40	0.51	1.42	143	610
28	7*0.12	0.51	1.38	239	610
	1*0.32	0.51	1.34	227	610
30	7*0.10	0.51	1.32	381	610
	1*0.254	0.51	1.274	361	610
注：根据供需双方协议，可以生产其他规格的产品。
